ELP Mini Industrial Camera High Frame Rate 60fps 480P Color CMOS OV7725 0.3MP VGA USB Webcam Camera UVC Plug Play For Computer Camera
Package Include
1pc of 0.3MP USB Camera with M12 Mount fixed focus lens
1pc of USB Cable supplied ,standard 3meter
Features
*0.3MP USB Camera VGA Camera Module.max resolution 640x480,
*High Frame Rate 60fps 480P ,VGA 60FPS
*YUY2 and MJPEG compression format optional
*CMOS sensor 1/4" inch OV7725 for high quality image and low power consumption
*High speed USB 2.0 interface for high resolution PC camera interface plug and play, no need any drivers.
*Super small outline and thin profile for embedded applications(Mini size 32*32/26*26mm)
*UVC Compliant, for use in most operation system ,include Android ,Linux ,Windows, Mac
*Standard M12 Mount FIXED FOCUS lens ,standard 25mm long focal length, optional M12 Mount different viewing angle lens
Main Specifications
|
Model |
ELP-USB30W02M-L25 |
|
Sensor |
OV7725 |
|
Lens Size |
1/4 inch |
|
Pixel Size |
6.0um X 6.0um |
|
image area |
3984 µm x 2952 µm |
|
Max. Resolution |
640(H)X480(V) |
|
Compression format |
MJPEG / YUV2（YUYV） |
|
Resolution & frame |
640X480 MJPEG@ 60fps YUY2@ 30fps/ 480X480 MJPEG@ 30fps YUY2@ 30fps 450X450 MJPEG@30fps YUY2@ 30fps/ 352X288 MJPEG@ 30fps YUY2@ 30fps 320X240 MJPEG@30fps YUY2@ 30fps/ 240X240 MJPEG@ 30fps YUY2@ 30fps |
|
S/N Ratio |
50dB |
|
Dynamic Range |
60dB |
|
Sensitivity |
3.8V/lux-sec@550nm |
|
Mini illumination |
0. 2lux |
|
Shutter Type |
Electronic rolling shutter / Frame exposure |
|
Connecting Port type |
USB2.0 High Speed |
|
Free Drive Protocol |
USB Video Class（UVC） |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gamma, |
|
Lens Parameter |
Standard 25mm, optional 2.1/2.5/2.8/6mm/ FOV(D)170 Degree |
|
Night vision |
Need to equipped IR Sensor Lens and IR LED Board |
|
LED board power connector |
Support 2P-2.0mm socket |
|
Power supply |
USB BUS POWER 4P-2.0mm socket |
|
Power supply |
DC5V |
|
Operating Voltage |
100mA~160mA |
|
Working current |
-10～70℃ |
|
Working temperature |
-20～85℃ |
|
Board size /Weight |
32X32mm（Compatible 26X26mm）/ about 30g |
|
Cable |
Standard 1M / optional 2M,3M,5M |
|
Operating system request |
WinXP/Vista/Win7/Win8 Linux with UVC（above linux-2.6.26） MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
